摘要
随着科技水平的进步与发展，出现了许多以计算机软件运用相结合的机械设计的方法，为设备的研发以及制造奠定了坚实的基础。为了能够开发更先进的螺旋输送机，对螺旋输送机设备的发展前景有着重要的研究意义。当今的时代，螺旋输送机对于机械行业来说是机械加工中重要的设备，因此它们的研究功能以及发展状况也促进了螺旋输送机整个行业的发展。当前我国的螺旋输送机机械行业的内在潜在价值还有待强有力的挖掘，螺旋输送机的进一步研究将会给企业乃至整个机械行业和社会带来重要的积极意义，在研究的同时还可以让学生的综合能力得到开发与锻炼，最为重要的是总体设计就体现了这一点。第一，我们要让现在毕业的学生打好专业知识的基础并从而提升所学的知识，从而在以后工作中能够游刃有余。第二，可以让他们在课题中能够用发展性的眼光看待问题，充分发挥创新能力，攻破现实难题。对于螺旋输送机设计这一课题，它的涵知识面较广，具有极强的综合性，学生则必须要凭借过硬的专业能力和海量的知识，加上要有一定的在计算机上绘制图表的能力。因此，学生可以积极主动的思考和钻研这个设计课题，这样学生便可以在问题的分析解决上得到能力的提升，从而也能够积累对未来有帮助的工作经验。 [资料来源：http://doc163.com]
这篇论文会对国内螺旋输送机的历来的情况进行一个简要的概述，而且加上了螺旋输送机工作的理念简述，综述国内外螺旋输送机的现在的发展情况后，也综合了它的装置构造是如何设计概念。论文中，做好了螺旋输送机构造与设计的方案，对该装置的参数进行设计，校对其强度，分析其运动，螺旋输送机的每个机械构造和尺寸分别得到确认和完善。
关键词：螺旋输送机；螺旋轴；连续运输
Abstract
With the advancement and development of the level of science and technology, there have been many methods of mechanical design combined with the use of computer software, which have laid a solid foundation for the R&D and manufacturing of equipment. In order to develop a more advanced screw conveyor, it has important research significance for the development prospects of screw conveyor equipment. In today's era, screw conveyors are important equipment for mechanical processing in the machinery industry, so their research capabilities and development status have also promoted the development of the screw conveyor industry as a whole. At present, the inherent potential value of the screw conveyor machinery industry in China needs to be tapped vigorously. Further research on the screw conveyor will bring important positive significance to the enterprise and the entire machinery industry and society. It can also enable students to study at the same time. The overall capabilities have been developed and exercised, and the most important is that the overall design reflects this. First, we must let the now-graduated students lay the foundation for professional knowledge and thus enhance the knowledge they have learned so that they can do their job in the future. Second, they can allow them to look at issues with a development perspective in their projects, give full play to their innovative capabilities, and break through real-world problems. For the subject of screw conveyor design, it has a wide range of culvert knowledge and is extremely comprehensive. Students must rely on excellent professional skills and vast knowledge, plus they must have a certain degree of computer graphics. ability. Therefore, students can actively think and delve into this design topic, so that students can gain the ability to analyze and solve problems, and thus can also accumulate work experience that will help the future.
[资料来源：Doc163.com]
This paper will give a brief overview of the historical situation of screw conveyors in China and add the concept of screw conveyor work. After reviewing the current development situation of screw conveyors at home and abroad, it also integrates the How device design is designed. In the thesis, a scheme for the construction and design of the screw conveyor was made. The parameters of the device were designed, the strength of the proofreading, and the movement were analyzed. Each mechanical structure and size of the screw conveyor was confirmed and improved.
Keywords screw conveyor； screw axis； continuous transportation
[版权所有：http://DOC163.com]
