基于MATLAB的无刷双馈电机建模与仿真

基于MATLAB的无刷双馈电机建模与仿真(论文10000字)
摘要：本文叙述无刷双馈电机的发展过程和研究意义，分析无刷双馈电机的基本结构和数学模型，利用MATLAB对无刷双馈电机进行建模仿真，使其能够进行异步运行和同步运行，并观察在这两种运行方式下无刷双馈电机的转子转速、电磁转矩以及电流的变化，分析这两种运行方式下所获的转子转速波形图、电磁转矩波形图和电流波形图并与理论进行比较，最后得出无刷双馈电机具有异步电机和同步电机的优良特性，可以作为异步电机和同步电机来使用的结论。
关键词：无刷双馈电机；异步运行；同步运行；建模仿真

Modeling and Simulation of Brushless Doubly-Fed Machine Based on MATLAB
Abstract: This paper describes the development process and research significance of brushless doubly-fed electric machine, analyzes the basic structure and mathematical model of brushless doubly-fed machine, and uses MATLAB to model and simulate the brushless doubly-fed motor, so that it can run asynchronously and synchronously. Observe the changes of rotor speed, electromagnetic torque and current of the brushless doubly-fed motor in these two modes of operation, and analyze the rotor speed waveform, electromagnetic torque waveform and current waveform obtained under these two modes of operation. Compared with the theory, the conclusion is that the brushless doubly-fed motor has the excellent characteristics of asynchronous motor and synchronous motor, which can be used as asynchronous motor and synchronous motor. [来源：http://www.doc163.com]
Key words: Brushless doubly-fed machine; asynchronous operation; synchronous operation; modeling and simulation
  [资料来源：http://doc163.com]
