锤式破碎机设计(含cad零件图装配图)
资料介绍:
锤式破碎机设计(含cad零件图装配图)(含任务书,开题报告,毕业设计说明书24000字,外文翻译,cad图纸)
摘要:锤式破碎机大量应用于水泥厂、电厂等各个部门,所以,它的设计有着广泛的前景和丰富的可借鉴的经验。
其设计的实质是,在完成总体的设计方案以后,就指各个主要零部件的设计、安装、定位等问题,并对个别零件进行强度校核和试验。并在相关专题中,对锤头的寿命延长进行比较详细的分析。在各个零部件的设计中,要包括材料的选择、尺寸的确定、加工的要求,结构工艺性的满足,以及与其他零件的配合的要求等。在强度的校核是,要运用的相关公式,进行危险部位的分析、查表、作图和计算等。并随后对整体进行安装、工作过程以及工作后的各方面的检查,同时兼顾到维修、保险装置等方面的问题,最后对两个主要工作零件的加工精度、公差选择进行分析,以保证破碎机最终设计的经济性和可靠性。
关键词: 锤式破碎机 锤头 强度 公差
Hammer Crusher Design
英文摘要
Abstract:Hammer type breakers are applied to such each department as the cement plant , power plant ,etc. in a large amount, so its design has an extensive prospect and experience that can be used for reference.
[资料来源:https://www.doc163.com]
Its design essence is, formerly after total conceptual design, a design which points each main spare part , question of installing and making a reservation etc., and carry on the intensity to check and test tothe specific part, and in relevant thematic parts, analysis of comparing question that the life-span of very beginning of the hammer lengthens in detail . In the design of each spare part , should include the choice , sureness , demand processed , structure craft satisfication of the size of the material , and the demand for cooperating with other parts, etc.. When the intensity is checked , should use relevant formulae , carry on the analysis of the dangerous position, need to check form , mapping , calculation ,etc.. Then to to install , work course , work situation after predict that carries on more overall inspection whole, give consideration to the question in such respects as maintaining and safety ,etc. at the same time . Finally , choose to analyse in machining accuracy , public errand to two groundwork parts, economy and dependability that the breaker soed as to ensure is designed finally. [来源:http://Doc163.com]
Key Words: Hammer type breakers hammer intensity tolerance
毕 业设计(论文)使用的原始资料(数据)及设计技术要求:
1. 破碎机的破碎对象是:石灰石、煤块、焦碳、石膏等软物料;
2. 生产能力:30 m3/h;
3. 转子的直径D=800mm,转子的长度L=800mm ;
4. 最大物料给料粒度:小于150 ;
5、最大排料粒度不能超过:10 。
