Abstract
The double wishbone suspension is used as the rear suspension of the Haval H6 SUV. Since the double wishbone independent suspension has a different construction from the conventional suspension, it can improve the handling stability and comfort of the car, so it is widely used in the suspension layout of modern cars, and it is also a kind of advanced suspension form.
In this graduation design project, the basic parameters and positioning parameters of the double wishbone independent suspension will be designed first, and then the parameters of the various components of the steering mechanism of the suspension are analyzed and calculated according to the design experience and the design formula. Also according to the basic parameters of the suspension, these design parameters are checked and modified. After completing the parametric design of all parts, Catia will be used to model three-dimensional modeling of the suspension and get the overall assemble of the system. Finally, by using the simulink module of Matlab, I build a two-degree-of-freedom vibration system model of the car, then input the basic parameters of the designed suspension to verify the reliability and comfort of the suspension.

Keywords: double wishbone suspension, CATIA modeling, simulink, ride comfort analysis


[资料来源：Doc163.com]

Content
Abstract    3
Keywords: double wishbone suspension, CATIA modeling, simulink, ride comfort analysis    3
Chapter 1 Introduction    5
1.1 Background of Research    5

1.2 The purpose and content of the graduate design    5
Chapter 2 Automobile Suspension    6
2.1 The composition and function of car suspension    6
2.2 Design Requirements for Vehicle Suspensions    6
2.3 Classification of Vehicle Suspensions    7
Chapter 3 Determination of Main Parameters    8
3.1Design of the main suspension parameters    9
3.1.1 Suspension Static Deflection Design    9
3.1.2 Suspension Dynamic Deflection Design    10
3.1.3 Suspension Elastic Properties    11
3.1.4 Suspension work range    12
3.1.5 Calculation of suspension stiffness    12
3.2 Suspension guide mechanism design    12
3.2.1 Plane arrangement of upper and lower horizontal arms in the longitudinal plane    13
3.2.2 Plane layout of upper and lower horizontal arms in horizontal plane    13
3.2.3 Upper and lower cross arm length design    14
3.2.4 Roll Center    15
3.3 Design of Helical Spring    16
3.3.1 Design of Spring Geometric Parameters    17
3.3.2 Checking the spring    20
3.4 shock absorber design    20
3.4.1 Selection of Shock Absorber Types    21
3.4.2 Selection of main parameters    21
3.5 Design of lateral stabilizer bar    24
Chapter 4. Analysis of automobile ride comfort based on MATLAB SIMULINK    25
4.1The purpose of the research of vehicle smoothness and research methods.    25
4.2 The establishment of 1/4 model    26
4.3 The establishment of pavement incentive model    27
Chapter 5. Summary    31
Reference    32
Acknowledgement    34 [版权所有：http://DOC163.com]
