现代车辆设计介绍

现代车辆设计介绍(中文5000字,英文2500字)
1.车身建模
1.1 粘土模型
图4.10全尺寸粘土模型的展示
    许多公司都钟爱银，因为它显示形式非常好且易“翻折”，这意味着通过改变表面角度可以使其对光性非常好。 在修正的整个过程中，设计师re-Dinoc和管理层的代表可能会进行几次不同时间间隔的审查，然后才会最终批准。
    这些设计评审在设计过程的关键阶段进行。 他们涉及造型，工程，营销和管理，这意味着模型需要一定量的场地来展示。该模型将被完全“指出”，即在每个十线网格交叉处检查所有的维度和表面坐标，并且在复杂区域中更频繁地检查。 然后将其传递给工程人员，然后将生成最终的车体表面线图。
    “扫描/铣削”类型的数字控制建模桥用于在表面上跟踪，并且所有坐标将被存储并数字化到工程CAD系统中，从中将产生车体表面线图。

An Introduction to ModernVehicle Design
Figure4.10Presentationoffullsizeclaymodel
silver is a favourite in many companies, as it shows form very well and ‘flips’, which means where surfaces change angle towards the light it contrasts very well. The whole process of modification, review by the stylists, re-Dinoc and presentation to management may take place severaltimesatvariousintervalsbeforethefinalapprovalisgiven.

[资料来源：http://www.doc163.com]

Thesedesignreviewsareperformedatcriticalstagesofthedesignprocess.Theyinvolve
styling, engineering, marketing and management, which means that the models are presented with a certain amount of theatre.The model will be fully ‘pointed off’, this means that all of the dimensional and surface coordinates will be checked at each ten-line grid intersection, and more frequently in complex areas. It will then be passed to engineering who will then generate thefinalbodysurfacelinedrawing.
